Dayton Stainless Steel 33" X 22" X 8" 1-Hole Equal Double Bowl Dual Mount Sink, DPXSR233221
- In Production
- Brand: Elkay
- Model # DPXSR233221
Dayton offers a complete line of stainless steel sinks, along with drains and accessories. From drop-in installation to undermount and dual mount styles, Dayton sinks come in an array of sizes and bowl configurations. You'll also find packages to meet every budget. Our products are backed with the quality assurance of domestic manufacturing and great customer service.
- Slim Rim: Install sink as a drop-in or undermount; ultrathin, flat rim virtually eliminates the barrier between sink and counter for a clean look
- DOUBLE BOWLS OF EQUAL SIZE: Conveniently use bowls independently for washing, soaking, rinsing, drying and other household tasks
- 18-GAUGE STAINLESS STEEL: Crafted from high-quality 18-gauge thickness and 300 Series stainless steel for lasting durability
- QUIET: Sound-deadening pad(s) minimizes sound and vibration for a quieter time at the sink
- U-CHANNEL INSTALLATION: Mounting clips placed inside the channel before installation means less time under the sink for an easier install
- OFFSET DRAIN: Drain placement provides more usable space on the bottom of the sink and in the cabinet below
- MADE IN THE USA: This Elkay product is proudly made in the USA
- DRAIN OPENING: Sink drain opening measures 3-1/2"
- CABINET SIZE: Minimum cabinet size for this sink is 36"
| ASME Standards | ASME A112.19.3 |
| Bowl Split | 50/50 |
| Brand | Elkay |
| Countertop Cutout Dimensions | 32-3/8" x 21-3/8" (822mm x 543mm) with 1-1/2" (38mm) corner radius |
| CSA Standards | CSA B45.4 |
| Drain Placement Bowl 1 | Rear Center |
| Drain Placement Bowl 2 | Rear Center |
| Drain Size Bowl 1 | 3.5 |
| Drain Size Bowl 2 | 3.5 |
| Drainboard Type | No drainboard |
| Gallons To Overflow | 6.5 |
| Length Bowl 1 | 14.5 |
| Length Bowl 2 | 14 |
| Minimum Cabinet Size Inches | 36 |
| NPCC | Yes |
| Number Faucet Holes Required | 1 |
| Prop 65 Warning | Yes |
| Shape Bowl 1 | Other |
| Shape Bowl 2 | Other |
| Sink Depth | 8 |
| Sound Deadening | Bottom only pads |
| Specifications | Spec Sheet Installation Warranty |
| Width Bowl 1 | 18.3125 |
| Width Bowl 2 | 18 |
| Product Type | Sink |
| Collection | Dayton® |
| Color | Premium Highlighted Satin |
| Width (in) | 22 |
| Length (in) | 33 |
| Height (in) | 8 |
| Material | Stainless Steel |
| Weight (lb) | 22.89 |
| Ada Compliant | No |
| Application | Residential/MultiFamily |
| Gauge | 18 |
| Installation | Drop-in;Undermount |
| Number of Bowls | 2 |
| UPC Listed | cUPC |
