Elkay has been a trusted name in stainless steel since 1920. We are proud to be America's No. 1 selling kitchen sink company. In addition, we offer prep, bar, bath and laundry sinks. Elkay commercial sinks can be found in public spaces such as classrooms, office buildings, health care facilities, parks and recreation areas and more. Available in ADA depths.
- 16-gauge, Type 304 stainless steel
- Large die-drawn sink compartments pitched to drain
- Seamless drawn 3-1/2" radius coved corners
- Exposed surfaces blended into a lustrous satin finish
- Steel channel-reinforced drainboards have a conical shaped pitch for drainage
- 8" high, full-length backsplash with 45-degree sloped top to resist dirt and grime
- 2" thick backsplash to allow for plumbing
- 3-1/2" drain opening centered in each compartment
- Stainless steel tubular legs with cross-brace supports
- 1-5/8" OD with up to 1" adjustable bullet-shaped stainless steel feet
| ASME Standards | ASME A112.19.3 |
| Backsplash Height | 6 |
| Brand | Elkay |
| CSA Standards | CSA B45.4 |
| Drain Placement Bowl 1 | Center Center |
| Drain Placement Bowl 2 | Center Center |
| Drain Placement Bowl 3 | Center Center |
| Drain Size Bowl 1 | 3.5 |
| Drain Size Bowl 2 | 3.5 |
| Drain Size Bowl 3 | 3.5 |
| Drainboard Type | Left and Right |
| Length Bowl 1 | 18 |
| Length Bowl 2 | 18 |
| Length Bowl 3 | 18 |
| NPCC | Yes |
| Number Faucet Holes Required | 4 |
| Prop 65 Warning | Yes |
| Sink Depth | 14 |
| Specifications | Spec Sheet Warranty |
| Width Bowl 1 | 24 |
| Width Bowl 2 | 24 |
| Width Bowl 3 | 24 |
| Product Type | Cis |
| Collection | Elkay®,Rigidbilt® |
| Color | Buffed Satin |
| Width (in) | 29.75 |
| Length (in) | 97.5 |
| Height (in) | 42.25 |
| Material | Stainless Steel |
| Weight (lb) | 160 |
| Ada Compliant | No |
| Application | Foodservice |
| Gauge | 16 |
| Installation | Scullery |
| Number of Bowls | 3 |
| UPC Listed | cUPC |
